Description
Operating Weight:
5952#
Controls
SAE or ISO
Travel Speed:
0-2.2mph
Grade Ability:
35%
Ground Pressure:
5.51 PSI
Engine:
Kubota D1105
Rated Power:
14.1kw(20HP) 2400rpm
Max Flow
11.89gpm
Fuel Tank:
6.87 Gallons
More Info:
Side Swing: Yes
Retracting Tracks: Yes
Bucket Capacity: 2.83 cubic ft
Bucket Width: 16”
Arm Length: 39.37”
Bucket Digging Force: 4383.77#
Arm Digging Force: 2472.9#
Cylinders: 3
Cooling Type: Water-cooling
Main Pump: Variable Piston Pump
Hydraulic Tank: 7.9 Gallons
Hydraulic System: Variable Piston
Engine Oil: 5.28 Qt
Fuel Consumption: .4-.5 Gallons/Hour
Overall Length: 153.54”
Overall Width: 51.18-59.06”
Overall Height: 93.7”
Superstructure Width: 49.21”
Ground Clearance: 6”
Track Length: 66.93”
Track Shoe Width: 9.84”
Total Track Width: 51.18-59.06”
Min. Front Swing Radius: 29.53”
Max. Digging Radius: 151.97”
Max. Digging Depth: 100.00”
Max Digging Height: 156.69”
Max Dumping Height: 103.94”
